DAC12AU
Digital to Analogue Converter (DAC) - Simultaneous Analogue and Digital Output



Description

Our DAC12AU is designed to convert either coaxial or optical signals from a digital signal to analogue stereo audio. The DAC12AU also includes a digital converter which converts optical audio in to a coaxial digital output. This provides the perfect cost effective solution when connecting the digital audio output from a TV display to an analogue input on an amplifier. The DAC12AU utilises 192kHz sample rates for enhanced sound reproduction.

Box Contents

1 x DAC12AU
1 x 5V/1A DC power supply
1 x Mounting kit
1 x User manual


Downloads

Key Features

  • DAC (Digital to Analogue audio Converter) converts either Optical or Coaxial digital to analogue stereo Left / Right audio output

  • Converts Optical digital audio input to Coaxial digital audio output

  • Auto-detects digital connection in use

  • Optical digital input has priority over Coaxial digital input

  • Outputs Coaxial digital and analogue L/R audio concurrently*

  • Supports sample rates 32 kHz, 44.1kHz, 48 kHz, 96 kHz & 192 kHz up to 24-bit resolution

  • Plug-and-play
    * DAC12AU does not down mix Dolby / dts / multi-channel audio signals

Specifications

  • Audio Input Connectors: 1 x optical digital & 1 x coaxial RCA (S/PDIF)

  • Audio Output Connectors: 2 x Analogue stereo left / right & 1 x Coaxial RCA (S/PDIF)

  • Dimensions (W x H x D): 50mm x 26mm x 42mm

  • Dimensions including connections (W x H x D): 68mm x 26mm x 42mm

  • Shipping Weight: 0.4kg

  • Operating Temperature: 32°F to 104°F (0°C to 40°C)

  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)

  • Power Supply: 5V/1A DC
