DA11AU
2ch Analogue Audio to Dante® Converter



Description

Our DA11AU has been designed to convert unbalanced or balanced 2ch analogue audio to Dante® digital signal. The DA11AU allows any non-Dante® audio source such as mixing consoles, amplifiers, computers, and Blustream Matrix or distribution products to be connected as a source within a Dante® network. The DA11AU is a plug & play device that is powered using PoE (Power over Ethernet) from any PoE network switch and supports AES67 RTP audio transport.

Box Contents

1 x DA11AU
1 x Quick Reference Guide


Downloads

Key Features

  • Analogue audio inputs support both balanced and unbalanced audio signals

  • Supports 44.1, 48 & 96KHz sample rates @ 24 bit

  • Configurable Dante® device latency (supports 1, 2 or 5ms configurable using Dante® Controller)

  • Supports AES67 RTP audio transport

  • Features Class 1 802.3af PoE for powering of product from any PoE switch

Specifications

  • Audio Input Connectors: 6-PIN Phoenix connector (2ch balanced / un-balanced analogue audio)

  • Audio Output Connectors: 1 x RJ45, female (100Mbps Dante® network)

  • Casing Dimensions (W x H x D): 120mm x 23mm x 34mm

  • Shipping Weight: 0.2kg

  • Operating Temperature: 32°F to 104°F (0°C to 40°C)

  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)

  • Power Supply: Class 1 IEEE 802.3af POE PD
