New Custom Pro HDBaseT Matrix featuring 4K HDR Support - In Stock

Blustream is delighted to announce the arrival of the first HDBaseT matrix solutions that support 4K HDR resolutions.

The Custom Pro range is expanding with a host of new 4K HDR supported boards.  What do we mean by that?  We mean that by using our advanced Colour Space Conversion the Custom Pro supports 18Gbps 60 Hz 4:4:4 (4K HDR)

With a Custom Pro Matrix you can choose the configuration that best suits your client; we have also prepared some pre-configured alternatives that boast audio breakout, simultaneous HDBaseT/HDMI outputs, RS-232 pass through and a web browser interface module for enhanced control. The New Custom Pro solution is the perfect choice for installations that aspire to deliver the very latest 4K HDR resolutions.


PRO48HBT70CS
Custom Pro 4x8 HDBaseT CSC Matrix (4K 60Hz 4:4:4 up to 40m) - Supports 4K HDR, IP Control, PoE, 2-Way IR and Audio Breakout

Description

Our Custom Pro 4x8 HDBaseT™ CSC Matrix offers unprecedented 4K HDR performance for the custom installation market. The PRO48HBT70CS is a HDMI2.0 4K 60Hz 4:4:4 HDCP2.2 Matrix utilising CSC technology to deliver HDMI, Bi-directional IR, PoH (PoE) up to lengths of 70m over a single CAT cable (4K with HDR up to 40m). The Matrix also provides advanced features including audio breakout and a web browser interface module for control and configuration of the matrix.

Key Features

  • HDBaseT™ technology offering distribution of video and audio over a single CAT cable
  • Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
  • Features 4x HDMI inputs which can be independently routed to 8 x HDBaseT™ outputs
  • Supports 4K 60Hz 4:4:4 UHD video up to 40m
  • Extends HDMI 1080p video up to 70m
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K HDR
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • Analogue audio input can be embedded onto any HDMI input
  • Web interface module for control and configuration of Matrix
  • Supports bi-directional IR
  • Supplied with Blustream IR receivers and emitters
  • Control via front panel, IR, RS-232 and TCP/IP
  • Supports PoH (Power over HDBaseT™) to power compatible HDBaseT™ receivers
  • 3rd Party drivers available for all major home control brands
  • 2U Design for 19" rack mount integration - Mounting kit included
  • Advanced EDID management
  • HDCP2.2 compliant

Specifications

  • Video Input Connectors: 4 x HDMI Type A, 19-pin, female
  • Video Output Connectors:  8 x HDBaseT™ RJ45 connector
  • Audio Input Connectors: 8 x 3.5mm stereo jack (L/R)
  • TCP/IP Control: RJ45, female
  • Ethernet/Network: RJ45, female
  • IR Input ports: 9x 3.5mm stereo jack
  • RS-232 serial port: DB-9, female
  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 440mm x 87mm x 282m without feet
  • Dimensions Including Connections (W x H x D): 440mm x 94mm x 288mm with feet
  • Shipping Weight: 5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/6A DC

PRO88HBT70CS
Custom Pro 8x8 HDBaseT CSC Matrix (4K 60Hz 4:4:4 up to 40m) - Supports 4K HDR, IP Control, PoE, 2-Way IR, 4 x Simultaneous HDMI outputs , Audio Breakout with volume control

Description

Our 70m Custom Pro 8x8 HDBaseT™ CSC Matrix offers unprecedented 4K HDR performance for the custom installation market. The PRO88HBT70CS is a HDMI2.0 4K 60Hz 4:4:4 HDCP2.2 Matrix utilising CSC technology to deliver HDMI, Bi-directional IR, PoH (PoE) up to lengths of 70m over a single CAT cable (4K HDR up to 40m).

The Matrix also provides advanced features including 8 x simultaneous HDMI outputs, audio breakout with line level pre amp volume control and a web browser interface module for control and configuration of the matrix.

Key Features

  • HDBaseT™ technology offering distribution of video and audio over a single CAT cable
  • Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
  • Features 8 x HDMI inputs which can be independently routed to 8 x HDBaseT™ outputs
  • Supports 4K 60Hz 4:4:4 UHD video up to 40m
  • Supports 4K with HDR
  • Extends HDMI 1080p video up to 70m
  • 8 x Simultaneous HDMI Outputs
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K HDR
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • 8 x simultaneous coaxial digital and variable line-level analogue L/R audio outputs
  • Analogue audio input can be embedded onto any HDMI input
  • Web interface module for control and configuration of Matrix
  • Supports bi-directional IR
  • Supplied with Blustream IR receivers and emitters
  • Control via front panel, IR, RS-232 and TCP/IP
  • Supports PoH (Power over HDBaseT™) to power compatible HDBaseT™ receivers
  • 3rd Party drivers available for all major home control brands
  • 2U Design for 19" rack mount integration - Mounting kit included
  • Advanced EDID management
  • HDCP 2.2 compliant

Specifications

  • Video Input Connectors: 8 x HDMI Type A, 19-pin, female
  • Video Output Connectors:  8 x HDBaseT™ RJ45 connector, 4 x HDMI Type A, 19-pin, female
  • Audio Input Connectors: 8 x 3.5mm stereo jack (L/R)
  • TCP/IP Control: RJ45, female
  • Ethernet/Network: RJ45, female
  • IR Input ports: 9x 3.5mm stereo jack
  • RS-232 serial port: DB-9, female
  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 440mm x 87mm x 282m without feet
  • Shipping Weight: 5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/6A DC

PRO88HBT100CS
Custom Pro 8x8 HDBaseT CSC Matrix (4K 60Hz 4:4:4 up to 70m) - Supports 4K HDR, IP & RS-232 Control, PoE, 2-Way IR, 4 x Simultaneous outputs, Audio Breakout with volume control

Description

Our 100m Custom Pro 8x8 HDBaseT™ CSC Matrix offers unprecedented 4K HDR performance for the custom installation market. The PRO88HBT100CS is a HDMI2.0 4K 60Hz 4:4:4 HDCP2.2 Matrix utilising CSC technology to deliver HDMI, Bi-directional IR, PoH (PoE) up to lengths of 100m over a single CAT cable (4K HDR up to 70m).The Matrix also provides advanced features including 4 x simultaneous HDMI outputs, audio breakout with line level pre amp volume control and a web browser interface module for control and configuration of the matrix.

Key Features

  • HDBaseT™ technology offering distribution of video and audio over a single CAT cable
  • Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
  • Features 8 x HDMI inputs which can be independently routed to 8 x HDBaseT™ outputs
  • Supports 4K 60Hz 4:4:4 UHD video up to 70m
  • Supports 4K with HDR
  • Extends HDMI 1080p video up to 100m
  • 4 x Simultaneous HDMI Outputs
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K HDR
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • 8 x simultaneous coaxial digital and variable line-level analogue L/R audio outputs
  • Analogue audio input can be embedded onto any HDMI input
  • Web interface module for control and configuration of Matrix
  • Supports bi-directional IR
  • Supplied with Blustream IR receivers and emitters
  • Control via front panel, IR, RS-232 and TCP/IP
  • Supports PoH (Power over HDBaseT™) to power compatible HDBaseT™ receivers
  • 3rd Party drivers available for all major home control brands
  • 2U Design for 19" rack mount integration - Mounting kit included
  • Advanced EDID management
  • HDCP 2.2 compliant
  • To be used with the HEX100CS-RX receivers

Specifications

  • Video Input Connectors: 8 x HDMI Type A, 19-pin, female
  • Video Output Connectors:  8 x HDBaseT™ RJ45 connector, 4 x HDMI Type A, 19-pin, female
  • Audio Input Connectors: 8 x 3.5mm stereo jack (L/R)
  • TCP/IP Control: RJ45, female
  • Ethernet/Network: RJ45, female
  • IR Input ports: 9x 3.5mm stereo jack
  • RS-232 serial port: DB-9, female
  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 440mm x 87mm x 282m without feet
  • Dimensions Including Connections (W x H x D): 440mm x 94mm x 288mm with feet
  • Shipping Weight: 5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/6A DC

PRO4V4H8HBT70
Custom Pro 8x8 HDBaseT CSC Matrix (4K 60Hz 4:4:4 up to 40m) - 2 x VGA Input, 2 x HDMI Input, HDR, IP Control, PoE, 2-Way IR, 4 x Simultaneous HDMI outputs , Audio Breakout with volume control

Description

Our Custom Pro HDMI / VGA 8x8 HDBaseT™ CSC Matrix offers unprecidented 4K HDR performance for the custom installation market. The PRO4V4H8HBT70 is a HDMI2.0 4K 60Hz 4:4:4 HDCP2.2 Matrix utilising CSC technology to deliver 2 x HDMI 2 x VGA, Bi-directional IR and PoH (PoE) up to lengths of 100m over a single CAT cable (4K HDR up to 70m).

The Matrix also provides advanced features including 4 x simultanious HDMI outputs, audio breakout with line level pre amp volume control and a web browser interface module for control and configuration of the matrix.

Key Features

  • HDBaseT™ technology offering distribution of video and audio over a single CAT cable
  • Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
  • Features  4 x HDMI inputs and 2 x VGA inputs which can be independently routed to 8 x HDBaseT™ outputs
  • Supports 4K 60Hz 4:4:4 UHD video up to 40m
  • Supports 4K HDR
  • Extends HDMI 1080p video up to 70m
  • 4 x Simultanious HDMI Outputs
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K HDR
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • 8 x simultaneous coaxial digital and variable line-level analogue L/R audio outputs
  • Analogue audio input can be embedded onto any HDMI input
  • Web interface module for control and configuration of Matrix
  • Supports bi-directional IR
  • Supplied with Blustream IR receivers and emitters
  • Control via front panel, IR, RS-232 and TCP/IP
  • Supports PoH (Power over HDBaseT™) to power compatible HDBaseT™ receivers
  • 3rd Party drivers available for all major home control brands
  • 2U Design for 19" rack mount integration - Mounting kit included
  • Advanced EDID management
  • HDCP 2.2 compliant

Specifications

  • Video Input Connectors: 4 x HDMI Type A, 19-pin, female, 4 x VGA
  • Video Output Connectors:  8 x HDBaseT™ RJ45 connector, 4 x HDMI Type A, 19-pin, female
  • Audio Input Connectors: 8 x 3.5mm stereo jack (L/R)
  • TCP/IP Control: RJ45, female
  • Ethernet/Network: RJ45, female
  • IR Input ports: 9x 3.5mm stereo jack
  • RS-232 serial port: DB-9, female
  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 440mm x 87mm x 282m without feet
  • Dimensions Including Connections (W x H x D): 440mm x 94mm x 288mm with feet
  • Shipping Weight: 5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/6A DC

PRO88HDMI-V2
Custom Pro 8x8 HDMI Matrix  - Supports 4K HDR, IP Control,  2-Way IR

Description

Our Custom Pro 8x8 HDMI Matrix delivers 4K 18Gbps HDR performance for the custom installation market. The PRO88HDMI-V2 is a HDMI2.0 4K60Hz 4:4:4 HDCP2.2 Matrix featuring Bi-directional IR and a web browser interface module for control and configuration of the matrix.

Key Features

  • Features 8 x HDMI inputs which can be independently routed to 8 x HDMI outputs
  • Supports 18 Gbps 4K UHD video including HDR, HDR10+ and Dolby Vision
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
  • Control via front panel, IR, RS-232 & TCP/IP
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP 2.2 compliant

Specifications

  • Video Input Connectors: 8 x HDMI Type A, 19-pin female
  • Video Output Connectors:  8  x HDMI Type A, 19-pin, female
  • Audio Input Connectors: 8 x 3.5mm stereo jack (L/R)
  • TCP/IP Control: RJ45, female
  • Ethernet/Network: RJ45, female
  • RS-232 serial port: DB-9, female
  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 440mm x 87mm x 282m without feet
  • Dimensions Including Connections (W x H x D): 440mm x 94mm x 288mm with feet
  • Shipping Weight: 5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/6A DC

New 18Gbps HDMI 2.0 Products in stock!


Its going to be a busy few weeks ahead as we enter a summer that will see over 25 new pioneering products launched. At Blustream it is engrained in our philosophy to drive our industry forward with market leading product innovation and customer support. Our latest range of HDBaseT matrix and extenders that support 4K 60Hz 4:4:4 (Including HDR) will be arriving in less than 2 weeks, however the following new HDMI 2.0 solutions have arrived now and are already shipping.


CMX44AB
Contractor 4x4 HDMI2.0 4K HDCP2.2 Matrix with Audio Breakout, EDID Management and IR Routing


Description

Our Contractor CMX44AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market.

The CMX44AB supports HDMI2.0 and HDCP2.2, allowing distribution of four HDMI sources to four displays. This enables all sources to be viewed as required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 4-Way matrix also includes audio breakout and EDID management.

Key Features

  • Features 4x HDMI inputs which can be independently routed to 4x HDMI outputs
  • Supports HDMI2.0 18Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
  • Control via front panel, IR and RS-232
  • IR routing
  • Supplied with Blustream 5V IR receivers and emitters
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP2.2 compliant

Specifications

  • Video Input Connectors: 4x HDMI Type A, 19-pin, female, locking
  • Video Output Connectors: 4x HDMI Type A, 19-pin, female, locking
  • Audio Output Connectors: 4x RCA (S/PDIF), 4x Analogue audio L/R (3.5mm stereo Jack)
  • RS-232 serial port: DB-9, female
  • IR Input ports: 5x 3.5mm stereo jack
  • IR Output ports: 4x 3.5mm mono jack
  • Mounting kit included
  • Unit Dimensions (WxDxH):  313mm x 129mm x 45mm (without feet or connections)
  • Unit Dimensions (WxDxH):  313mm x 140mm x 47mm (with feet and connections)
  • Shipping Weight: 2.2kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/2A DC

CMX42AB
Contractor 4x2 HDMI2.0 4K HDCP2.2 Matrix with Audio Breakout, EDID Management and IR Routing


Description

Our Contractor CMX42AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market.

The CMX42AB supports HDMI2.0 and HDCP2.2, allowing distribution of four HDMI sources to two displays. This enables all sources to be viewed as required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 4-Way matrix also includes audio breakout and EDID management.

Key Features

  • Features 4x HDMI inputs which can be independently routed to 2x HDMI outputs
  • Supports HDMI2.0 18Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
  • Control via front panel, IR and RS-232
  • IR routing
  • Supplied with Blustream 5V IR receivers and emitters
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP2.2 compliant

Specifications

  • Video Input Connectors: 4x HDMI Type A, 19-pin, female, locking
  • Video Output Connectors: 2x HDMI Type A, 19-pin, female, locking
  • Audio Output Connectors: 2x RCA (S/PDIF), 2x Analogue audio L/R (3.5mm stereo Jack)
  • RS-232 serial port: DB-9, female
  • IR Input ports: 3x 3.5mm stereo jack
  • IR Output ports: 4x 3.5mm mono jack
  • Mounting kit included
  • Unit Dimensions (WxDxH):  255mm x 104mm x 40mm (without feet or connections)
  • Unit Dimensions (WxDxH):  255mm x 115mm x 47mm (with feet and connections)
  • Shipping Weight: 1.6kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/2A DC

SP12AB-V2
2-Way 4K HDMI splitter with Audio Breakout and EDID Management


Description

Our SP12AB-V2 4K HDMI 2.0 splitter distributes a single HDMI source to two simultaneous outputs. The splitter supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4.

Key Features

  • Features 1x HDMI input  that is replicated to 2x HDMI outputs
  • Supports HDMI 2.0 18 Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
  • HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
  • Advanced EDID management
  • HDCP 2.2 Support

Specifications

  • Video Input Connectors: 1x HDMI Type A
  • Video Output Connectors: 2x HDMI Type A
  • EDID: 4-PIN DIP switch
  • Audio Output Connectors: 1x RCA (SPDIF), 1x Analogue audio L/R (3.5mm stereo Jack)
  • Dimensions (W x D x H): 159mm x 64mm x 23mm , without feet
  • Shipping Weight: 0.6kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 5V/1A DC

SP14AB-V2
4-Way 4K HDMI splitter with Audio Breakout and EDID Management


Description

Our SP14AB-V2 4K HDMI 2.0 splitter distributes a single HDMI source to four simultaneous outputs. The splitter supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4.

Key Features

  • Features 1x HDMI input  that is replicated to 4x HDMI outputs
  • Supports HDMI 2.0 18 Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
  • HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
  • Advanced EDID management
  • HDCP 2.2 Support

Specifications

  • Video Input Connectors: 1x HDMI Type A
  • Video Output Connectors: 4x HDMI Type A
  • EDID: 4-PIN DIP switch
  • Audio Output Connectors: 1x RCA (SPDIF), 1x Analogue audio L/R (3.5mm stereo Jack)
  • Dimensions (W x D x H): 203mm x 84mm x 23mm , without feet
  • Shipping Weight: 0.5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 5V/2A DC
