PRO88HDMI
Pro 8x8 HDMI Matrix - 2-Way IR and Audio Breakout

The PRO88HDMI is a configured 4K HDCP 2.2 compliant 8x8 HDMI matrix. The matrix also provides advanced audio breakout features. The Custom Pro Matrix has been specifically designed to operate in challenging AV environments. Its robust housing and interlocking board configuration make both installation and maintenance a seamless experience



Key Features

  • Features 4 x HDMI inputs which can be independently routed to video output cards
  • Supports up to 4K UHD video (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
  • Control of Matrix via front panel, RS-232, TCP/IP and web GUI
  • Quick release card module fittings allowing simple population of input and output cards
  • Web interface module for control and configuration of Matrix
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP 2.2 compliant

Specifications

  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 440mm x 87mm x 282m without feet
  • Dimensions Including Connections (W x H x D): 440mm x 94mm x 288mm with feet
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 24V/6A DC

Box Contents

  • 1x PRO88HDMI matrix
  • 1x 24V/6A power supply
  • 1x Remote control
  • 1x Rack mounting kit
  • 1x Quick reference guide
