PRO88HBT70
Pro 8x8 HDBaseT Matrix (70m) - 2-Way IR, RS-232 and Audio Breakout, simultaneous HDMI output

Description

The PRO88HBT70 is a configured 4K HDCP 2.2 compliant 8x8 HDBaseT matrix, transmitting HDMI, Bi-directional IR and PoH (PoE) up to lengths of 70m (1080p) over a single CAT cable. The matrix also provides advanced features including audio breakout, simultaneous HDMI outputs and RS-232 pass through to enable seamless 3rd party control integration. The Custom Pro Matrix has been specifically designed to operate in challenging AV environments. Its robust housing and interlocking board configuration make both installation and maintenance a seamless experience



Key Features

  • Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
  • Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
  • Features 8 x Simultaneous HDMI/HDBaseT™ outputs for connection to HDMI displays and HDBaseT™ receivers
  • Features 8 x Bi-directional RS-232 ports for serial communication to corresponding HDBaseT™ zone receivers
  • Features 8 x HDMI audio breakouts from corresponding video zone outputs to coaxial digital and analogue L/R audio outputs
  • 8x IR inputs for distribution of IR to compatible HDBaseT™ receivers
  • Control of Matrix via front panel, RS-232, TCP/IP and web GUI
  • Quick release card module fittings allowing simple population of input and output cards
  • Supports PoH (Power over HDBaseT™) when used with compatible HDBaseT™ input/output cards
  • Web interface module for control and configuration of Matrix
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP 2.2 compliant

Specifications

  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 440mm x 87mm x 282m without feet
  • Dimensions Including Connections (W x H x D): 440mm x 94mm x 288mm with feet
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 24V/6A DC

Box Contents

  • 1x PRO88HBT70
  • 1x 24V/6A power supply
  • 1x Remote control
  • 1x Rack mounting kit
  • 1x Quick reference guide
