New 18Gbps HDMI 2.0 Products in stock!


Its going to be a busy few weeks ahead as we enter a summer that will see over 25 new pioneering products launched. At Blustream it is engrained in our philosophy to drive our industry forward with market leading product innovation and customer support. Our latest range of HDBaseT matrix and extenders that support 4K 60Hz 4:4:4 (Including HDR) will be arriving in less than 2 weeks, however the following new HDMI 2.0 solutions have arrived now and are already shipping.


CMX44AB
Contractor 4x4 HDMI2.0 4K HDCP2.2 Matrix with Audio Breakout, EDID Management and IR Routing


Description

Our Contractor CMX44AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market.

The CMX44AB supports HDMI2.0 and HDCP2.2, allowing distribution of four HDMI sources to four displays. This enables all sources to be viewed as required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 4-Way matrix also includes audio breakout and EDID management.

Key Features

  • Features 4x HDMI inputs which can be independently routed to 4x HDMI outputs
  • Supports HDMI2.0 18Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
  • Control via front panel, IR and RS-232
  • IR routing
  • Supplied with Blustream 5V IR receivers and emitters
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP2.2 compliant

Specifications

  • Video Input Connectors: 4x HDMI Type A, 19-pin, female, locking
  • Video Output Connectors: 4x HDMI Type A, 19-pin, female, locking
  • Audio Output Connectors: 4x RCA (S/PDIF), 4x Analogue audio L/R (3.5mm stereo Jack)
  • RS-232 serial port: DB-9, female
  • IR Input ports: 5x 3.5mm stereo jack
  • IR Output ports: 4x 3.5mm mono jack
  • Mounting kit included
  • Unit Dimensions (WxDxH):  313mm x 129mm x 45mm (without feet or connections)
  • Unit Dimensions (WxDxH):  313mm x 140mm x 47mm (with feet and connections)
  • Shipping Weight: 2.2kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/2A DC

CMX42AB
Contractor 4x2 HDMI2.0 4K HDCP2.2 Matrix with Audio Breakout, EDID Management and IR Routing


Description

Our Contractor CMX42AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market.

The CMX42AB supports HDMI2.0 and HDCP2.2, allowing distribution of four HDMI sources to two displays. This enables all sources to be viewed as required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 4-Way matrix also includes audio breakout and EDID management.

Key Features

  • Features 4x HDMI inputs which can be independently routed to 2x HDMI outputs
  • Supports HDMI2.0 18Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
  • Control via front panel, IR and RS-232
  • IR routing
  • Supplied with Blustream 5V IR receivers and emitters
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP2.2 compliant

Specifications

  • Video Input Connectors: 4x HDMI Type A, 19-pin, female, locking
  • Video Output Connectors: 2x HDMI Type A, 19-pin, female, locking
  • Audio Output Connectors: 2x RCA (S/PDIF), 2x Analogue audio L/R (3.5mm stereo Jack)
  • RS-232 serial port: DB-9, female
  • IR Input ports: 3x 3.5mm stereo jack
  • IR Output ports: 4x 3.5mm mono jack
  • Mounting kit included
  • Unit Dimensions (WxDxH):  255mm x 104mm x 40mm (without feet or connections)
  • Unit Dimensions (WxDxH):  255mm x 115mm x 47mm (with feet and connections)
  • Shipping Weight: 1.6kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/2A DC

SP12AB-V2
2-Way 4K HDMI splitter with Audio Breakout and EDID Management


Description

Our SP12AB-V2 4K HDMI 2.0 splitter distributes a single HDMI source to two simultaneous outputs. The splitter supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4.

Key Features

  • Features 1x HDMI input  that is replicated to 2x HDMI outputs
  • Supports HDMI 2.0 18 Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
  • HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
  • Advanced EDID management
  • HDCP 2.2 Support

Specifications

  • Video Input Connectors: 1x HDMI Type A
  • Video Output Connectors: 2x HDMI Type A
  • EDID: 4-PIN DIP switch
  • Audio Output Connectors: 1x RCA (SPDIF), 1x Analogue audio L/R (3.5mm stereo Jack)
  • Dimensions (W x D x H): 159mm x 64mm x 23mm , without feet
  • Shipping Weight: 0.6kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 5V/1A DC

SP14AB-V2
4-Way 4K HDMI splitter with Audio Breakout and EDID Management


Description

Our SP14AB-V2 4K HDMI 2.0 splitter distributes a single HDMI source to four simultaneous outputs. The splitter supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4.

Key Features

  • Features 1x HDMI input  that is replicated to 4x HDMI outputs
  • Supports HDMI 2.0 18 Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
  • HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
  • Advanced EDID management
  • HDCP 2.2 Support

Specifications

  • Video Input Connectors: 1x HDMI Type A
  • Video Output Connectors: 4x HDMI Type A
  • EDID: 4-PIN DIP switch
  • Audio Output Connectors: 1x RCA (SPDIF), 1x Analogue audio L/R (3.5mm stereo Jack)
  • Dimensions (W x D x H): 203mm x 84mm x 23mm , without feet
  • Shipping Weight: 0.5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 5V/2A DC
