Now in Stock - MX44VW 4x4 4k Seamless Switching HDMI / VGA Matrix with Video Wall & Multi Viewer Feature

Our MX44VW 4K HDMI/VGA matrix is a multi-purpose high-speed video processing system. The MX44VW can be configured for 3 different output modes. The MX44VW can perform as a 4x4 seamless matrix switcher, as a 2x2, 4x1 or 1x4 video wall solution, and as a quad multi-view presentation system. Inputs can be assigned as either HDMI or VGA with associated L/R analogue audio with control of the switcher via the front-panel push buttons, IR remote control, RS-232 interface and TCP/IP.


Features 3 operational modes:
* 4x4 Matrix (selected HDMI or VGA inputs)
* Video wall (2x2, 4x1 or 1x4 configuration)
* Multi-viewer mode with preset layouts

▪ Features 4x video inputs that can be configured as HDMI video or VGA video with associated L/R analogue audio
▪ Seamless video switching
▪ Video inputs support all industry standard video resolutions including VGA-WUXGA (up to 1920x1200 @60Hz) and 480i-4K (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
▪ HDMI output resolution fixed to 1080p 60Hz
▪ Supports HDMI 2ch PCM audio only
▪ IR routing
▪ Supplied with Blustream IR receivers and emitters
▪ Control via front panel, IR, RS-232 and TCP/IP
▪ 3rd Party control drivers available for all major home control brands
▪ Advanced EDID management
▪ HDCP compliant
